Fanvil WF20 USB Wi-Fi Dongle

This Fanvil WF20 USB Wi-Fi Dongle is a compact and high-performance solution that adds wireless connectivity to compatible Fanvil IP phones. Supporting IEEE 802.11b/g/n wireless standards on the 2.4 GHz band, it delivers data rates of up to 150 Mbps, allowing for seamless voice communication over Wi-Fi networks. The plug-and-play USB 2.0 interface ensures effortless installation, while advanced Wi-Fi security protocols like WPA and WPA2 safeguard data transmission. Ideal for modern workspaces, the WF20 enables flexible device placement without being limited by Ethernet cabling.

Product Features

High-Speed Wireless Performance
The WF20 supports wireless data transmission speeds of up to 150 Mbps, enabling fast and stable connectivity for VoIP applications.

Wide Compatibility
This dongle works with multiple Fanvil IP phone models including X5S, X6, X4U, X5U, X6U, X7, X7C, X210, and X210i. Specific firmware versions may be required to ensure full functionality.

Secure Wireless Communication
The device supports advanced wireless security protocols including WPA, WPA2, WPS 2.0, and WAPI, providing robust protection for voice and data traffic.

Plug and Play Installation
With a USB 2.0 interface, the WF20 enables easy setup without the need for complex configurations or additional drivers, making it highly user-friendly.

Compact and Lightweight Design
Measuring just 33 x 16 x 7 mm and weighing only 50 grams, the WF20 is discreet and space-saving, fitting easily into tight setups without obstruction.

LED Status Indicators
Integrated LED lights give users visual feedback on the power and connectivity status, simplifying troubleshooting and connection monitoring.

Environmental Resilience
Built to operate in environments ranging from 0°C to 45°C and 20% to 85% humidity, the WF20 is durable and reliable in typical office conditions.

Product Specifications

• Network Standards: IEEE 802.11b/g/n
• Transmission Rate: Up to 150 Mbps
• Frequency Range: 2.4 GHz
• Security Protocols: WPA, WPA2, WFA, WPS 2.0, WAPI
• Interface: USB 2.0
• Working Temperature: 0°C – 45°C
• Working Humidity: 20% – 85% (non-condensing)
• Color: Black
• Device Dimensions: 33 x 16 x 7 mm
• Weight: Approx. 50 grams
• Compatible Phones: Fanvil X5S, X6, X4U, X5U, X6U, X7, X7C, X210, X210i (2.4GHz only)
• Firmware Requirements:
  • X5S/X6/X210/X210i: V1.10.10 or higher
  • X7/X7C: V1.0.10 or higher
